The tables below describe the software packages available and offer links to current versions, as well as selected older versions which may be needed for some projects.eBUS SDK for JAI
Product Overview The eBUS Player, included with the purchase of a Developer Seat License and also available as a free download, is an easy-to-use solution to both view streams and develop, test, and evaluate advanced application features. The eBUS Player allows users to control the parameters of imaging sources by providing access to the GenICam-compliant XML. This whitepaper discusses how several factors contribute to latency in driving applications and will share Pleora's test bench set-up and results with regards to military vetronics and the Pleora RuggedCONNECT Smart Video Switcher. What You’ll Learn: Why low latency is a key metric for military driving applications.
The eBUS SDK for JAI is a powerful new SDK for building vision systems that utilize JAI cameras. It is based on the eBUS SDK by Pleora and is specifically designed for use only with JAI cameras. The eBUS SDK for JAI consists of an SDK (Software Development Kit) and a Player.
The eBUS Player is application software for directly accessing and controlling JAI cameras in a non-programmatic way. It can be used for testing and evaluation of JAI cameras with GigE Vision or USB3 Vision interfaces.The SDK is packaged software that enables system developers to easily build programs for integrating JAI cameras into vision systems.
About this software 'eBUS SDK for JAI'
All intellectual property rights and ownership, including copyrights of this software product, are retained by Pleora. Be sure to check the software license agreement included in the software package and you can use this software only if you can agree.
About cameras that can use this software
For a JAI camera to use this software, it must satisfy the following two conditions.
- It must have an interface of either GigE Vision, or USB3 Vision
- It must have a CMOS image sensor
Specifically, the list of supported cameras is as described below. (As of December 2020)
Go-X Series: All models
Go Series: GO-2400M/C-USB, GO-2400M/C-PGE, GO-2401M/C-PGE, GO-5000M/C-USB, GO-5000M/C-PGE, GO-5100M/C-USB, GO-5100M/C-PGE, GO-5101M/C-PGE, GO-5100MP-PGE, GO-5100MP-USB
Spark Series: SP-5000M/C-USB, SP-12401M/C-PGE, SP-12401M/C-USB, SP-20000M/C-USB
Apex Series: AP-3200T-10GE, AP-3200T-USB, AP-3200T-USP-LS, AP-3200T-USB-LSX, AP-3200T-PGE, AP-1600T-USB, AP-1600T-USB-LS, AP-1600T-USB-LSX, AP-1600T-PGE
Fusion Series: FS-1600D-10GE, FS-1600T-10GE-NNM, FS-3200D-10GE, FS-3200T-10GE-NNC, Fusion Series Flex-Eye custom multispectral cameras
Sweep Series: SW-4000TL-10GE, SW-4000TL-SFP
Sweep+ Series: SW-4000T-10GE, SW-4000T-SFP, SW-4000Q-10GE, SW-4000Q-SFP, SW-8000T-10GE, SW-8000T-SFP, SW-8000Q-10GE, SW-8000Q-SFP
Read more on our Frequently Asked Questions (FAQ) page, or download from the table below.
| Software / Documentation | Version | Link |
|---|---|---|
| eBUS SDK for JAI (32-bit) | 6.1.4 (Windows) - 30 MB | download |
| eBUS SDK for JAI (64-bit) | 6.1.4 (Windows) - 49 MB | download |
| eBUS Player User Guide (PDF) | 6.1 - 30 July 2019 | download |
| Revision Notes (PDF) | 11 Dec. 2019 | download |
| JAI SDK to eBUS Migration Guide (PDF) | 02 April 2019 | download |
| OLDER VERSIONS - 5.1.10 | ||
| eBUS SDK for JAI (32-bit) | 5.1.10 (Windows) - 28 MB | download |
| eBUS SDK for JAI (64-bit) | 5.1.10 (Windows) - 45 MB | download |
| eBUS Player User Guide (PDF) | 5.1 - 08 May 2018 | download |
| OLDER VERSIONS - 5.1.3 | ||
| eBUS SDK for JAI (32-bit) | 5.1.3 (Windows) - 28 MB | download |
| eBUS SDK for JAI (64-bit) | 5.1.3 (Windows) - 44 MB | download |
Note: Windows 10, Windows 8.1, Windows 7 (x86 and x86_64) Service Pack 1 or later are supported.
Linux and Linux for ARM support
The eBUS SDK for JAI is available in several Linux versions, as well as a version compatible with the Linux for ARM processors in the NVIDIA Jetson family of embedded processor boards.
The table below lists the Linux versions currently available. Click on a link to be taken a page providing downloads and instructions for that version.
| Software Version | Link |
|---|---|
| Red Hat Enterprise Linux 7 and CentOS 7 64-bit on x86 architecture | Go to download page |
| Ubuntu 14.04, 16.04 LTS, and 18.04 LTS 64-bit on x86 architecture | Go to download page |
| Ubuntu 14.04 and 16.04 LTS 32-bit on i686 architecture | Go to download page |
| Ubuntu 18.04 64-bit ARM architecture for NVIDIA Jetson Nano, TX2/TX2i, and AGX Xavier | Go to download page |
Camera Link Control Tools
All of JAI's Camera Link cameras have software control. The latest recommended version of the camera control tools can be downloaded, free of charge, on the Downloads page or in the Downloads tab of the product page associated with a specific model.
Please note: While the JAI SDK and Control Tool may work with many of the Camera Link models, it is no longer supported and is NOT recommended for development of any production systems.
JAI SDK and Control Tool
IMPORTANT: As of April 1, 2020 the JAI SDK and Control Tool is no longer supported by JAI. The final versions of this software are available for download below. While we consider the software to be in good working order, if any bugs are found, they will not be fixed -- REGARDLESS OF THEIR CRITICALITY!
Users of GigE Vision and USB3 Vision cameras are strongly advised to use the eBUS SDK for JAI, which is available above.
If you are using a Camera Link camera, separate Control Tool software can be downloaded from the product page for your camera. Likewise, if you are using a camera with a CoaXPress interface, you are strongly encouraged to use the control tool provided with your selected frame grabber.
For simple testing and GUI-enabled control of Camera Link or CoaXPress cameras, you are welcome to try the JAI SDK and Control Tool software. However, we cannot guarantee that it will work with all cameras - especially the newest models - nor can we guarantee it to work with future upgrades of operating systems or camera firmware. Using it for development of production systems isnot advised and is done at your own risk.
Downloads
The table below provides access to the final versions of this software, as well as links to selected older versions which may be needed for legacy systems.
| Software / Documentation | Version | Link |
|---|---|---|
| JAI SDK and Control Tool (32-bit) | 3.0.7 (Windows) - 85.8 MB | download |
| JAI SDK and Control Tool (64-bit) | 3.0.7 (Windows) - 111 MB | download |
| Getting Started Guide (PDF) | Rev M - 31 Mar 2016 | download |
| Latest Release Notes (PDF) | 3.0.7 - 07 Sep 2018 | download |
| OLDER VERSIONS - 3.0.4 | ||
| JAI SDK and Control Tool (32-bit) | 3.0.4 (Windows) - 85.8 MB | download |
| JAI SDK and Control Tool (64-bit) | 3.0.4 (Windows) - 111 MB | download |
| Getting Started Guide (PDF) | Rev M - 31 Mar 2016 | download |
| OLDER VERSIONS - 2.1.6 | ||
| JAI SDK and Control Tool (32-bit) | 2.1.6 (Windows) - 98 MB | download |
| JAI SDK and Control Tool (64-bit) | 2.1.6 (Windows) - 126 MB | download |
| Getting Started Guide (PDF) | Rev L - 08 Jul 2015 | download |
| OLDER VERSIONS - 1.4.1 | ||
| JAI SDK and Control Tool (32-bit Full*) | 1.4.1 (Windows) - 54.4 MB | download |
| JAI SDK and Control Tool (64-bit Full*) | 1.4.1 (Windows) - 82.8 MB | download |
| JAI SDK and Control Tool (32-bit Reduced*) | 1.4.1 (Windows) - 9.0 MB | download |
| JAI SDK and Control Tool (64-bit Reduced*) | 1.4.1 (Windows) - 12.9 MB | download |
| Getting Started Guide (PDF) | Rev K - 16 Dec 2014 | download |
Pleora Driver
*Please note: In Version 1.4.1, both 'full' and 'reduced' versions are offered. The following redistributables are included in the “full” versions of the JAI SDK & Control Tool. You MUST have these already installed in order to use the “reduced” versions:
Product: Microsoft .NET Framework Version 2.0 Service Pack 2
32-bit installations Filename: NetFx20SP2_x86.exe
64-bit installations Filename: NetFx20SP2_x64.exe
Download URL: http://www.microsoft.com/download/en/details.aspx?id=1639
Versions 1.4.0 and earlier
| Software / documentation | Version | Link |
|---|---|---|
| JAI SDK and Control Tool (32-bit) | 1.4.0 (Windows) - 54.8 MB | download |
| JAI SDK and Control Tool (64-bit) | 1.4.0 (Windows) - 83 MB | download |
| JAI SDK and Control Tool (32-bit) | 1.3.0 (Windows) - 53 MB | download |
| JAI SDK and Control Tool (64-bit) | 1.3.0 (Windows) - 78.7 MB | download |
| JAI SDK and Control Tool (32-bit) | 1.2.5 (Windows) - 48 MB | download |
| JAI SDK and Control Tool (64-bit) | 1.2.5 (Windows) - 75 MB | download |
You are using an outdated browser!
Update your browser to display this website correctly. Update my browser now
Pleora’s eBUS™ Software Development Kit (SDK) is a feature-rich toolkit that allows developers to produce video applications in short timeframes, while reducing risk and lowering design and support costs. Pleora’s eBUS SDK features a large library of sample code, which serves as a quick-start platform for each development project and is fully GigE Vision compliant. The following instructions will explain how to use Lucid Vision cameras with Pleora eBUS SDK for Windows.
System Specifications
Pleora Usb3 Vision Driver
- Windows 10 Pro 64-bit, version 1709, build 16299.64
- eBUS SDK 5.0.0.4100 64-bit
Table of Contents
System Specifications
Prerequisites
eBUS Player
eBUS SDK Samples
Pleora Gige Vision Driver
Prerequisites
Installing the eBUS Universal Pro For Ethernet Filter Driver is recommended. You can install the eBUS Universal Pro For Ethernet Filter Driver using the eBUS Driver Installation Tool, which can be launched from the Start Menu. Click the Install button in the eBUS Driver Installation Tool to install the eBUS Universal Pro For Ethernet Filter Driver.
Verify the eBUS Universal Pro For Ethernet Filter Driver is installed in the Ethernet adapter’s properties window.
Pleora Driver Installation Tool
eBUS Player
Launch eBUS Player to launch Pleora’s image acquisition program. eBUS Player can be launched from the Start Menu.
Press to open the camera selection screen and connect to your camera.
Click to acquire images from the camera.
Click to stop acquiring images from the camera.
Click to control connection and communication settings between the host system and the camera.
Saia-burgess Controls Driver download. Click to control camera settings.
Click to open image stream settings and view performance statistics.
Click to release control of the camera.
eBUS SDK Samples
Pleora eBUS SDK installs sample programs in your Samples and SamplesDotNet folder. Please note that some of the included samples are not necessarily intended for GigE Vision devices.
